ASTM B424 Nickellegierung 825/ UNS N08825 Blatt/ Platte für Rohr
Grad: Alloy 625 /N06625 , Alloy 600 /N06600 ,Alloy 601 /N06601 , Alloy 718 /N07718, Alloy C276 /N10276 , Alloy 800 /N08000 , Alloy 825 /N08825 , Alloy 400 /N04400,etc
Standard: ASTM B168; ASTM B443; ASTM B670; ASTM B127;ASTM B162; ASTM B333; ASTM B575; ASTM B582; , etc
Oberfläche: Bright Annealed
Technologie: Cold Rolled
Ndt: Ultrasonic test; Penetrant Test
Inspektion: 100%
Verpackung: Pallet/Plywooden case
Qualitätssicherung: ISO & PED
Blatt | Platte | Streifen | |
Dicke | ＜ 6mm | ≥ 6 mm | 0,15 mm - 3mm |
WiDTH | ≤ 1200 mm | ≤2800 mm | ≤ 1000 mm |
LEngles | ≤ 3000 mm | ≤ 8000 mm | Als Kundenanforderung |
Nickellegierung 825 Chemical composition:
| % | Ni | Fe | Cr | C | Mn | Si | S | Mo | Cu | Ti | Al |
| min | 38 | 22 | 19.5 | 2.5 | 1.5 | 0.6 | |||||
| Max | 46 | 23.5 | 0.05 | 1 | 0.5 | 0.03 | 3.5 | 3 | 1.2 | 0.2 |
Features: Alloy 825 has excellent resistance to chloride-ion-induced stress corrosion cracking, reducing environments containing phosphoric and sulfuric acids, oxidizing environments containing nitric acid and nitrates, and pitting, crevice corrosion and intergranular corrosion. It has good mechanical properties at cryogenic temperatures to moderately high temperatures up to 538℃
